This polarizer is a variation of the Glan-Taylor polarizer with a steep angle for the cut in the prism, which reduces reflection loss at the expense of decreased field of view. It is specially designed and manufactured for high energy application such as laser system. The optical materials exhibit lower scattering and better surface quality. The extraordinary beam transmits through the prism; the ordinary beam is reflected off the hypotenuse and exits the side hole.
Don't see what you need? Request custom optics.
Material | Wavelength Range | Extinction Ratio | Diameter Tolerance | Parallelism | Surface Quality | Beam Deviation | Wavefront Distortion | Damage Threshold | Coating | Mount |
a-BBO or Calcite | a-BBO: 200-3500 nm, Calcite: 350-2300 nm | Calcite:<5x10-5; a-BBO:<5x10-6 | ±0.10 mm | <1 arc Min | 20/10 | < 3 arc minutes | λ/4@632.8nm | >500 MW/cm2 typical | MgF2 | Black anodized aluminum |
* All dimensions are in mm |
Part Number | Wavelength Rang | Extinction Ratio | Angular Field | Clear Aperturer | Outer Dia | Length | |
---|---|---|---|---|---|---|---|
Z-GLP080 | 350-2300 | <5x10-6 | >7.7 | 15 | 30 | 33 | Add to Quote |
Z-GLP075 | 350-2300 | <5x10-6 | >7.7 | 10 | 25.4 | 26 | Add to Quote |
Z-GLP070 | 350-2300 | <5x10-6 | >7.7 | 8 | 25.4 | 25 | Add to Quote |
Z-GLP065 | 350-2300 | <5x10-6 | >7.7 | 6 | 15 | 21 | Add to Quote |
Z-GLP060 | 700-3000 | <5x10-6 | >6.0 | 15 | 30 | 33 | Add to Quote |
Z-GLP055 | 700-3000 | <5x10-6 | >6.0 | 10 | 25.4 | 26 | Add to Quote |
Z-GLP050 | 700-3000 | <5x10-6 | >6.0 | 8 | 25.4 | 25 | Add to Quote |
Z-GLP045 | 700-3000 | <5x10-6 | >6.0 | 6 | 15 | 23 | Add to Quote |
Z-GLP040 | 300-700 | <5x10-6 | >6.0 | 15 | 30 | 33 | Add to Quote |
Z-GLP035 | 300-700 | <5x10-6 | >6.0 | 10 | 25.4 | 26 | Add to Quote |
Z-GLP030 | 300-700 | <5x10-6 | >6.0 | 8 | 25.4 | 25 | Add to Quote |
Z-GLP025 | 300-700 | <5x10-6 | >6.0 | 6 | 15 | 25 | Add to Quote |
Z-GLP020 | 200-270 | <5x10-6 | >6.0 | 15 | 30 | 39 | Add to Quote |
Z-GLP015 | 200-270 | <5x10-6 | >6.0 | 10 | 25.4 | 31 | Add to Quote |
Z-GLP010 | 200-270 | <5x10-6 | >6.0 | 8 | 25.4 | 31 | Add to Quote |
Z-GLP005 | 200-270 | <5x10-6 | >6.0 | 6 | 15 | 29 | Add to Quote |
