A Wollaston polarizer has wider field of view than other birefringent polarizers. The two prisms are cemented together. Both ordinary and extraordinary beams transmit through the prism, however, at a deviation angle of 15° to 45° depending on the wavelength.
Singlets are the simplest form of optical components. Although they exhibit spherical and chromatic aberrations, they are the most readily available and least expensive way to direct energy to a specific spot. Singlets are also offered in a wide variety of coatings to meet your needs and specifications.
Don't see what you need? Request custom optics.
Part Number | Separation Angle | Clear Aperturer | Outer Dia | Length | |
---|---|---|---|---|---|
Z-WLP080 | 16.7-22.5° 19°@980nm | 15 | 30 | 23 | Add to Quote |
Z-WLP075 | 16.7-22.5° 19°@980nm | 10 | 25.4 | 18 | Add to Quote |
Z-WLP070 | 16.7-22.5° 19°@980nm | 8 | 25.4 | 16 | Add to Quote |
Z-WLP065 | 16.7-22.5° 19°@980nm | 6 | 15 | 14 | Add to Quote |
Z-WLP020 | 15-27° 16°@800nm | 15 | 30 | 23 | Add to Quote |
Z-WLP015 | 15-27° 16°@800nm | 10 | 25.4 | 18 | Add to Quote |
Z-WLP010 | 15-27° 16°@800nm | 8 | 25.4 | 16 | Add to Quote |
Z-WLP005 | 15-27° 16°@800nm | 6 | 15 | 14 | Add to Quote |
